P2 SMARTPAD - Banpostech

Pago sin fricciones en cualquier entorno empresarial

P2 SMARTPAD se puede conectar a la terminal de escritorio sin problemas y puede admitir muchos métodos de pago sin efectivo. El soporte giratorio dedicado también ayuda a que sea accesible para todos nuestros clientes.

Alto rendimiento para pago sin problemas.

Multi-option payment support

Alimentación de diseño ergonómico una experiencia de usuario de alta gama

MAS INFORMACIÓN

P2 SMARTPAD Especificaciones Técnicas

Modelo

T6A10

Sistema Operativo

SUNMI OS
(*based on Android 9.0)

Procesador

Cortex-A53
quad-core 1.3GHz

Memoria

1GB RAM+8GB Flash;
2GB RAM+16GB Flash (optional)

Pantalla

4” color screen, WVGA;
480*800;
Capacitive multi-touch

Camera

Front: 0.3MP, FF 1D/2D barcode scanning 5MP, FF (optional) Photo-taking supported

NFC Reader

Type A&B card, MIFARE card;
ISO/IEC 14443, qUICS, PayPass, payWave

Magstripe Reader

1/2/3 track;
Bi-directional card reading;
ISO 7810/7811 compliant

IC Card Reader

Smart IC card;
ISO 7816/EMV compliant

PSAM Card Slot

2*PSAM

Micro SD Card Slot

1*Micro SD (up to 32GB)

Speaker

1*1W

MIC (Optional)

1*MIC

Wi-Fi

2.4GHz/5GHz
IEEE 802.11 a/b/g/n/ac

Bluetooth

Bluetooth 4.1, BLE

Keyboard

15 keys (10 numeric keys+5 function keys);
raised markings Backlit supported

Ports

1*RJ45 LAN port,1
*Type-C support RS232,
USB
1*Audio jack
1*Kensington

LAN

LAN 10/100Mbps

Power Adaper

Input: AC 100~240V
Output: DC 12V/1A
PoE, Powered USB,
Powered RS232 supported

Dimensions (L*W*H)

181.85*117.8*54.5mm

Ports

1* Type-C USB OTG
supported
1* Pogo pin on the back
for charging (Optional)

Battery

Removable lithium battery
7.2V / 2600mAh

Power Adapter

Input: AC 100 ~ 240V
Output: DC 5V / 2A
DC 5V / 1A (optional)

Dimensions (L*W*H)

213.7*82*29mm

Total Weight

465g

Total Weight

385g

Protection

IP53

Environment

Operating temp: -10°C~50°C
Storage temp: -20°C~70°C

Accessories (Optional)

Stylus Pen, Rotatable Mount, Customizable Multi-function Cable

Security

PCI PTS 6.x
